Scorpion A-6528-180kv V2
Product Description
The Scorpion A - Series line of motors was designed to be the most optimal and premier choice of motor for your freestyle or UAV airplane. We have achieved incredible performance through incredible efficiency. By optimizing the magnets in the rotor, and using the best quality 0.2mm thickness silicon steel stator sheets, and 2 x single strand 1.18mm enamel coated copper wire windings rated above 200C+, the performance and efficiency results are unlike anything we have seen before! Combined with a robust design which has been tested extensively by our world class team pilots for longevity and reliability, we feel this motor checks and exceeds all measurable categories!
The A-6528-180kv was designed for 90"- 95" Acrobatic Airplanes, or other Sport / UAV airplanes requiring up to 7200w of power. Compared to the -200kv version, this motor is designed to swing a larger / slower spinning prop in the 24" - 26" range on 12s battery.
Recommended Prop Selection :
24x10E / 24x13E (Carbon) / 25x10E / 26x8E
Recommended ESC -: Tribunus II+ 14-200A ESC SBEC
Acrobatic Weight Range -: 8.18kg - 12.7kg (18.0lbs - 28.0lbs)
Sport / UAV (single engine) Weight Range : - 12.7kg - 36kg (28.0lbs -80lbs)
Specifications
| Motor Kv | 180 RPM / Volt |
| Weight (Motor only) | 998g (35.20 oz) |
| Weight (including mount + Prop mount accessories) | 1115g (39.33 oz) |
| Motor Body Dimensions | 78.5 mm x 67.8mm (3.09" x 2.67") |
| External Shaft Diameter | 10mm |
| Continuous Current | 95A |
| Continuous Power | 4218 Watts |
| Peak Current* | 162A |
| Peak Power* | 7200 Watts |
| Max Rated Lipo Cell** | 12s |
| Stator Diameter | 65.0 mm (2.56 in) |
| Stator Thickness | 28 mm (1.10 in) |
| No. of Stator Arms | 12 |
| Magnet Poles | 14 |
| Motor Wind | 7T Delta |
| Motor Wire | 2-Strand x 1.18mm |
| No-Load Current (IO/20V) | 2.39 Amps |
| Motor Internal Resistance | 6.85 mΩ |
| *Our ratings are classified as TRUTHFUL. Continuous Current / Power correlates to actual sustainable power levels. Peak Power is for intermittent full throttle usage ranging from 5 - 60 seconds depending on use case and cooling* | |
| **Higher Cell Count possible with smaller prop usage** | |
Included in the Box
1 x Scorpion A-6528 BLDC Motor
1 x A-55/65 Cross Mount (stock)
4 x M4 Cross Mount Mounting Bolts
3 x Female 6mm Connectors
3 x Heat Shrink
3 x Scorpion Stickers
2 x M10 Nuts
Weight including packaging
1490g
